Static Shielding Ziplock bag

Discharge time: for 1000V to 100V <2sec

Effect Shielding: E <10nJ

Conforms to standards: PN–EN (IEC) 61340-5-1, PN–EN (IEC) 61340-5-3; PN–EN (IEC) 61340-4-8

Resistance surface: RS= 10^8-10^10

Thickness: 76μ

Transparency: 40%

Purchase not possible online, please contact us by email: info@atoo-electronics.com to define the needed characteristics and dimensions.

Available in different standard sizes (many dimensions available from 76 x 127mm to 508 x 590mm), possibility to customize the pockets.

Complies with EU directive: RoHS & REACH

Equipped with a zip lock offering a simple opening / closing solution.

Shielding bags are widely used in electronics industry and production of blanks, chips and elements, that are sensitive to small electrostatic discharges.

The bags have an inner layer designed to prevent charge buildup and an outer layer designed to provide static shielding to protect contents from external sources of static charge.

Mainly used in the EPA Area, during changes of the assembly places and transportation.

Provide Faraday effect shielding of an Electrostatic Discharge (ESD) and prevent the penetration of damaging electrostatic fields.

ESD symbol and traceability batch number.

For more detailed product information, please contact us directly.

A03000XXX
